Description
| Item | Specification |
| CNC Controller | SYNTEC 6TA-E |
| Machine appearance & protection | Semi-enclosure |
| Guideway type | Linear guideway |
| X-axis max. travel | 880 mm |
| Z-axis max. travel | 320 mm |
| Max. turning diameter | Tool post plate: 126 mm; Max. workpiece: 400 mm |
| X-axis max. rapid feed | 28 m/min |
| Z-axis max. rapid feed | 28 m/min |
| Spindle model | A2-5 |
| Spindle drawbar through hole | 46 mm |
| Spindle max. speed | 4500 r/min |
| Max. bar capacity | 45.5 mm |
| Tool mounting type | Gang-type |
| Tool center height | 63 mm |
| Tool shank size | Square tool 20×20; Boring bar Ø20 |
